• Rear axle, 3.42 ratio
• GVWR, 5550 lbs. (2517 kg) (CS15506 models only.)
• Trailering wire harness, connector in bumper
• Rear wheel drive
• Battery, heavy-duty 600 cold-cranking amps, maintenance-free with rundown protection and retained accessory power
• Trailering equipment, heavy-duty, includes trailering hitch platform, 7-wire harness, CHMSL wire and heavy-duty flasher (4-wire harness on SS model) ( 7-wire adaptor shipped loose in glove box.)
• Suspension, front independent
• Suspension, rear 5-link coil springs
• Stabilizer bars, front and rear
• Steering, power
• Exhaust, aluminized stainless-steel muffler and tailpipe
• Tools, mechanical jack and wheel wrench
• Key, single, 2-sided

• Wheels, 4 - 17" x 7" (43.2 cm x 17.8 cm) bright aluminum, includes center caps and steel spare (Upgradeable to (PD8) 4-18" x 8" (45.7 cm x 20.3 cm) polished aluminum wheels. Requires (QZD) P245/60R18 all-season, blackwall tires.)
• Tires, P245/65R17 on-/off-road, White outlined-letter (Upgradeable to (QZD) P245/60R18 all-season blackwall tires. Requires (PD8) 4-18" x 8" (45.7 cm x 20.3 cm) aluminum wheels.)
• Glass, Solar-Ray deep-tinted (all windows except light-tinted glass on windshield and driver-and front passenger-side glass)
• Luggage rack, roof-mounted, Black, adjustable with center and side rails
• Side rails, roof-mounted, Black
• Moldings, body-color bodyside
• Door handles, body-color
• Bumpers, front and rear body-color, rear step includes pad
• Grille, body-colored
• Headlamps, dual composite halogen with automatic exterior lamp control
• Fog lamps, front, halogen
• Daytime Running Lamps
• Mirrors, outside heated power-adjustable, manual-folding
• Glass, Solar-Ray light-tinted
• Wipers, front intermittent with pulse washers
• Wipers, rear intermittent with washer
• Body, liftgate with liftglass

• Audio system, AM/FM stereo with CD player, seek-and-scan, digital clock, auto-tone control, speed-compensated volume and TheftLock May be substituted with (UC6) AM/FM stereo with 6-disc CD changer or (UM8) AM/FM stereo with CD player and touch-screen navigation.
• Audio system controls, rear with headphone jacks (headphones not included)
• XM Satellite Radio. With a wide variety of programming, XM has something to excite any driver. Whether you want to be entertained or informed, to laugh, think, or sing, XM has the perfect channel for you - coast-to-coast, and in digital-quality sound. 3 trial months - no obligation (Available in the 48 contiguous United States. Required $12.95 monthly subscription sold separately after 3 trial months. All fees and programming subject to change. Subscription subject to customer agreement. For more information, visit gm.xmradio.com)

• Seats, front buckets with leather-appointed seating driver power lumbar control, adjustable outboard head restraints, 8-way power driver seat adjusters with power recliner
• Defogger, rear-window electric
• Remote Keyless Entry, programmable with 2 transmitters and panic button
• Theft-deterrent alarm system, content theft alarm, includes beeping horn and flashing lights
• Floor mats, color-keyed carpeted front and rear, removable
• Seats, second row split-folding
• Console, floor with CD storage
• Floor covering, full-floor color-keyed carpeting
• Quiet Package with strategically placed elements of sound insulation
• Steering wheel, leather-wrapped with mounted audio and Driver Information Center controls, includes theft-deterrent locking feature
• Driver Information Center, monitors different systems, includes trip computer, fluid levels and door ajar
• Warning tones, headlamp on, key-in-ignition, driver safety belt unfasten and turn signal on
• Tire pressure monitoring system
• Convenience Package, power windows and door locks, programmable with lighted switches, driver and front passenger Express-Down windows, power rear glass release and rear-window wiper/washer
• Cruise control, electronic with set and resume speed
• Air conditioning, dual-zone automatic climate control with individual climate settings for driver and right-front passenger
• Air conditioning, rear with heater
• Heater and defogger with front and side front door window defoggers and rear passenger heating ducts
• Glovebox, passenger-side of instrument panel
• Power outlets, auxiliary
• Mirror, inside rearview auto-dimming with 8-point compass display
• Console, overhead custom
• Universal Home Remote, includes garage door opener, 3-channel programmable
• Armrests, driver and passenger doors, padded
• Door trim, integral padded armrests and driver- and front passenger-side map pockets
• Headliner, Neutral-colored cloth with matching retainer moldings
• Visors, driver and front passenger illuminated vanity mirrors, padded with cloth trim, color-keyed
• Assist handles, front passenger and rear outboard
• Lighting, interior with theater dimming, cargo compartment, reading lights for front seats, second row dome light, door- and tailgate-activated switches and illuminated entry and exit feature
• Cup holders, front and rear
• Cargo tie downs, 5 in-floor, located in the rear compartment
• Cargo mat, rear

• StabiliTrak, Stability Control System
• Brakes, 4-wheel antilock, 4-wheel disc
• Theft-deterrent system, vehicle, PASSlock
• OnStar, 1-year of Safe and Sound plan. Includes Automatic Notification of Air Bag Deployment, Stolen Vehicle Location Assistance, Emergency Services, Roadside Assistance, Remote Door Unlock, OnStar Vehicle Diagnostics, Hands-Free Calling, AccidentAssist, and Remote Horn & Lights (OnStar services require vehicle electrical system (including battery), wireless service and GPS satellite signals to be available and operating for features to function properly. OnStar acts as a link to existing emergency service providers. Stolen Vehicle Location Assistance and remote Door Unlock success varies with conditions. OnStar Vehicle Diagnostics available on most 2004 MY and newer GM vehicles. Diagnostic capability varies by model. Visit onstar.com for system limitations and details. Not available with certain FDR order types. Not available with a ship-to of Puerto Rico or the Virgin Islands.)
• Air bags, frontal, driver and front passenger with Passenger Sensing System (Always use safety belts and the correct child restraints for your childs age and size. Even in vehicles equipped with air bags and the Passenger Sensing System, children are safer when properly secured in a rear seat. Never place a rear-facing infant restraint in the front seat of any vehicle equipped with an active frontal air bag. See the vehicles Owners Manual and child safety seat instructions for more safety information.)
• Air bags, head curtain side-impact, front and rear outboard seating positions (Head curtain side air bags are designed to help reduce the risk of head and neck injuries to front and rear seat occupants on the near side of certain side-impact collisions. Always use safety belts and the correct child restraints for your childs age and size, even in vehicles equipped with air bags. Children are safer when properly secured in a rear seat. See the vehicles Owners Manual and child safety seat instructions for more safety information.)
• Door locks, rear child security
• LATCH system (Lower Anchors and Top tethers for CHildren), for child safety seats
• Horn, dual note high and low

ENGINE, VORTEC 4.2L I6 SFI

• with transmission oil cooler (285 hp [212 kW] @ 6000 rpm
• 276 lb-ft of torque [374 Nm] @ 4600 rpm) (STD)

• Premium Smooth Ride Suspension Package
• 6 Speakers
• AM/FM radio: XM
• AM/FM Stereo w/CD Player/XM Satellite
• Bose Premium Audio Speaker System Feature
• CD player
• XM Satellite Radio
• Air Conditioning
• Front dual zone A/C
• Rear window defroster
• Power driver seat
• Power steering
• Power windows
• Remote keyless entry
• Traction control
• 4-Wheel Disc Brakes
• ABS brakes
• Dual front impact airbags
• Emergency communication system: OnStar Safe & Sound
• Front anti-roll bar
• Front wheel independent suspension
• Low tire pressure warning
• Occupant sensing airbag
• Overhead airbag
• Rear anti-roll bar
• Electronic Stability Control
• Front fog lights
• Fully automatic headlights
• Panic alarm
• Security system
• Speed control
• Black Assist Steps
• Bodyside moldings
• Bumpers: body-color
• Front License Plate Bracket
• Power door mirrors
• Roof rack
• Driver door bin
• Driver vanity mirror
• Front reading lights
• Illuminated entry
• Overhead Custom Console
• Passenger vanity mirror
• Rear reading lights
• Tachometer
• Tilt steering wheel
• Voltmeter
• Front Bucket Seats
• Front Center Armrest
• Reclining Front Bucket Seats
• Split folding rear seat
• Passenger door bin
• Trailering Wire Harness Connector In Bumper
• Alloy wheels
• Rear window wiper
• Variably intermittent wipers
• 3.42 Rear Axle Ratio

• Vehicle
• Rear Door Type: Liftgate
• Mileage
• EPA Fuel Economy Est - City (MPG): 14
• EPA Fuel Economy Est - Hwy (MPG): 20
• Electrical
• Cold Cranking Amps @ 0° F (Primary): - TBD -
• Maximum Alternator Capacity (amps): 150
• Cooling System
• Total Cooling System Capacity (qts): 13.9
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 2950
• Gross Axle Wt Rating - Rear (lbs): 3200
• Curb Weight - Front (lbs): 2300
• Curb Weight - Rear (lbs): 2016
• Gross Vehicle Weight Rating Cap (lbs): 5550
• Gross Combined Wt Rating (lbs): 10000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 5400
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 810
• Suspension
• Suspension Type - Front: Independent
• Suspension Type - Rear: Coil
• Spring Capacity - Front (lbs): 3100
• Spring Capacity - Rear (lbs): 3200
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 2950
• Axle Capacity - Rear (lbs): 3200
• Axle Ratio (:1) - Rear: 3.42
• Shock Absorber Diameter - Front (mm): 46
• Shock Absorber Diameter - Rear (mm): 36
• Stabilizer Bar Diameter - Front (in): 1.33
• Stabilizer Bar Diameter - Rear (in): 0.82
• Brakes
• Brake Type: Power
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.0 x 1.14
• Rear Brake Rotor Diam x Thickness (in): 12.8 x 0.78
• Tires
• Front Tire Order Code: QTR
• Rear Tire Order Code: QTR
• Spare Tire Order Code: ZNF
• Front Tire Size: P245/65R17
• Rear Tire Size: P245/65R17
• Spare Tire Size: P235/75R16
• Front Tire Capacity (lbs): 1793
• Rear Tire Capacity (lbs): 1793
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 17 x 7
• Rear Wheel Size (in): 17 x 7
• Spare Wheel Size (in): 16 x - TBD -
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Rack & Pinion
• Steering Ratio (:1), On Center: 20.4
• Steering Ratio (:1), At Lock: 20.4
• Turning Diameter - Curb to Curb (ft): 36.4
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: - TBD -
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 22.0
• Fuel Tank Location: - TBD -
• Doors
• Side Door Type: Swing-out
• Exterior Dimensions
• Wheelbase (in): 113.00
• Length, Overall w/rear bumper (in): 191.80
• Width, Max w/o mirrors (in): 74.70
• Height, Overall (in): 72.50
• Overhang, Front (in): 34.96
• Overhang, Rear w/bumper (in): 43.8
• Ground to Top of Load Floor (in): 32.1
• Ground Clearance, Front (in): 7.80
• Ground Clearance, Rear (in): 7.80
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Seat 1 (in): 80.1
• Cargo Area Length @ Floor to Seat 2 (in): 43.7
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): - TBD -
• Cargo Box (Area) Height (in): 39.6
• Cargo Volume to Seat 1 (ft³): 80.1
• Cargo Volume to Seat 2 (ft³): 41.0
• Interior Dimensions
• Passenger Capacity: 5
• Front Head Room (in): 40.20
• Front Leg Room (in): 46.90
• Front Shoulder Room (in): 58.50
• Front Hip Room (in): 56.00
• Second Head Room (in): 39.60
• Second Leg Room (in): 37.00
• Second Shoulder Room (in): 58.50
• Second Hip Room (in): 58.20
• Summary
• Vehicle Name: Chevrolet TrailBlazer
• Body Style: 4 Door
• Body Code: TB4
